Polypropylene Cam Lever Adaptor – 1/2in Female x 3/4in Thread

Glass-reinforced polypropylene cam lever adaptor designed to connect 1/2in female threaded fittings to 3/4in adaptor outlets.

This robust adaptor is manufactured from durable glass-reinforced polypropylene and rated for use across a wide temperature range. It provides reliable performance in agricultural, industrial and general-purpose applications requiring secure quick-connect functionality.

Key Features

• 1/2in female thread inlet with 3/4in adaptor outlet
• Glass-reinforced polypropylene construction
• Temperature-rated operation from -17.8°C to 47.8°C
• Pressure rated to 8.6 bar at 21.2°C ambient
• Compatible with standard 3/4in cam lever systems
• Lightweight and corrosion-resistant

Specifications

• Inlet: 1/2in female thread
• Outlet: 3/4in adaptor size
• Material: Glass-reinforced polypropylene (GRPP)
• Maximum pressure: 8.6 bar at 21.2°C; 6.4 bar at -17.8°C; 4.8 bar at 47.8°C
• Operating temperature range: -17.8°C to 47.8°C

Applications

• Agricultural fluid transfer and irrigation systems
• Industrial and workshop fluid distribution
• Water management and storage tank connections
• General-purpose hose and adaptor assemblies
• Outdoor and portable equipment plumbing
