Description
Camcup adaptor for large-bore hose connections with NPT female thread termination.
This 3in male camcup adaptor provides a secure connection to 3in NPT female threaded ports on tanks, pumps and distribution systems. Precision-moulded in reinforced polypropylene with a self-aligning ball mechanism, it delivers reliable dry-disconnect performance in storage and transfer applications.
Key Features
- 3in camcup male adaptor with 3in NPT female thread outlet
- Self-aligning ball mechanism with diamond-turned spherical surface for precise sealing
- FKM (Viton-type) seals for chemical compatibility
- Polypropylene body reinforced with fibreglass
- Stainless steel bolts throughout
- Minimal handle pressure required to open or close
Specifications
- Camcup inlet: 3in male
- Thread outlet: 3in NPT female
- Ball I.D.: 2½in
- Maximum pressure: 7 bar at 21°C / 5 bar at 65°C
- Seal material: FKM
- Body material: Fibreglass-reinforced polypropylene
Applications
- Tank interconnection and transfer line couplings
- Pump inlet and discharge connections
- Distribution system branch points
- Industrial fluid handling installations
- Storage facility plumbing
