Description
High-pressure 90° angle swivel with triple bearing system for reliable directional fluid transfer.
This nickel-plated brass swivel connector provides 90° directional change whilst maintaining rotational freedom. The triple stainless steel bearing system enables smooth 360° rotation under pressure, making it ideal for applications requiring frequent hose repositioning without kinking or damage.
Key Features
- Triple stainless steel bearing system for smooth rotation
- 90° angled connector body
- Nickel-plated brass construction
- 7mm internal diameter port
- No snap ring design
- Rated for water, oil and air transfer
Specifications
- Female thread: 3/8in BSP parallel
- Male thread: 3/8in BSP parallel
- Maximum pressure: 275 bar
- Maximum rotational speed: 30 rpm
- Maximum fluid temperature: 120°C
- pH range: 3–12
Applications
- High-pressure washer hose connections
- Hydraulic system angled feed lines
- Industrial fluid transfer systems
- Rotating nozzle and spray equipment
- Mobile and stationary pressure equipment
