Description
Product Overview
The Premium Heavy Duty Steel Bolt Clamp W1 is engineered for securing hose couplings into PVC and rubber hoses, making it an ideal choice for both workshop and on-site applications. This clamp is designed to provide superior performance and reliability.
Key Features
- W1 specification offers a minimum of 72 hours of corrosion resistance in salt spray testing, ensuring durability in harsh environments.
- The smooth underside and rolled band edges are specifically designed to prevent damage to the hose cover when tightened.
- High strength 8.8 grade T-bolt ensures optimum torque when tightened, providing a secure fit.
- Features three welding points that enhance strength and security.
- Recommended torque settings are provided for optimal tightening.
Dimensions & Specifications
| Dia. Size (mm) | Band Width (mm) | Band Thickness (mm) | Bolt Size | Torque Setting (Nm) |
|---|---|---|---|---|
| 17-28 | 18 | 0.6 | M5 | 4.5 |
| 29-43 | 20 | 0.8 | M6 | 8 |
| 44-67 | 22 | 1.2 | M7 | 16 |
| 68-130 | 24 | 1.5 | M8 | 25 |
| 131-252 | 26 | 1.5 | M10 | 50 |
Technical Specifications
- Corrosion Resistance: Minimum 72 hours in salt spray testing
- Material: Zinc plated mild steel for enhanced durability
- Strength Grade: 8.8 for high-performance securing
- Applications: Suitable for workshop and on-site use
FAQ
Q: What is the corrosion resistance of this clamp?
A: The clamp has a minimum of 72 hours of corrosion resistance in salt spray testing.
Q: How many welding points does this clamp have?
A: It features three welding points for increased strength and security.
Q: What are the recommended torque settings?
A: Torque settings are provided for optimal tightening based on the size of the clamp.
