Premium Low-Level Stainless Steel Bump Rail for Impact Protection with Modular Design and Robust Durability

Premium Low-Level Stainless Steel Bump Rail

This low-level stainless steel bump rail protection system is a stylish and versatile solution for impact protection.

Sudirectstock.co.ukle for both internal and external use, the low-level modular stainless steel provides durable and robust protection for window lines and brickwork while maintaining a modern, stylish image. The modular components of the range allow for easy planning and installation.

Available as floor-fixed low-level protection, it can also be fitted to columns or walls at any height.

Bumper Rail Features:

• Fully modular construction for easy installation
• 50mm x 14swg 304 grade stainless steel
• Surface fixed or potted support foot options
• Finished height ranges from 165mm to 205mm above finished floor level

Bumper Rail Product Placement:

Ideal for installation both internally and externally in entrance lobbies, along glazing lines, and perimeter walls at customer entrances, providing protection against damage from shopping trolleys.

Bump Rail Performance Criteria:

Designed to withstand impacts from customer trolleys and deflect impacts from structures.

Technical Specifications

• Grade 304 Stainless Steel
• Satin Polish 240 grit finish
• Tube diameter: 50mm
• Stainless Steel End Caps included to terminate runs

Installation Instructions

• Maximum position of 100mm from wall/glazing to back of extrusion
• Floor mounted with M10x80mm expandable Rawlshields and bolts
• Leg centres are typically 1.5 meters apart
• Height of top rail is typically 165mm high
• Mark the floor with a chalk line and place the first base flange at the start of the run so it runs parallel with the rail
• Use the rail to mark the next position of the base flange and continue this process for the remainder of the run
• Floor mounted slide-through legs must only be used where a concrete base or slab is available; do not install into blockwork or tarmac

For potted legs, a hole must be core drilled 150mm wide x 300mm deep. The hole should be backfilled with concrete, and the potted leg pushed into the concrete before it sets.

Joining spigots are required to join ISP lengths together, plus corner sections.

Dimensions & Specifications

Frequently Asked Questions

• What is the material of the bump rail? The bump rail is made from grade 304 stainless steel.
• Can this bump rail be used outdoors? Yes, it is sudirectstock.co.ukle for both internal and external use.
• How is the bump rail installed? It can be floor mounted or fitted to walls/columns as required.
